Buy now: £139.00
Citronic CM-8 STUDIO COMPACT MIXER WITH USB OUTPUT The Citronic CM 8 is a compact format mixing console with mic/line inputs (jack/XLR) and a stereo line channel. Mic/line channels have individual inserts and all channels have 3-band EQ and Aux controls. Phantom power of +48V is switchable to the XLR inputs for condenser microphones. Main output is via balanced 6.3mm jacks and a USB type B connector feeds main output and receives a master input for DAW applications. Compact, accessible design Channel inserts for Mic/line inputs Switchable +48V phantom power 3-band EQ for each channel USB digital audio input/output (Windows XP, Vista, 7 & Mac) Rack-mount ears supplied with CM8-STUDIO model Mic inputs 6 x balanced XLR Dimensions 60 x 350 x 230mm Weight 2.75kg Phantom power Switchable 48V (XLR inputs) Power supply 12Vac, 500mA (included) Frequency response: Inputs 20Hz-20kHz Line inputs L+R 6.3mm TRS jack Stereo input 6.3mm jack/RCA (-8 to +15dB / +13 to +60 parallel) SNR: Mic inputs 120dB E.I.N. SNR: Line inputs 95dB E.I.N. SNR: Stereo input 96dB E.I.N. (or 104dB E.I.N. in parallel) EQ: High10kHz, ±15dB EQ: Mid700Hz, ±15dB EQ: Low50Hz, ±15dB Outputs: Main (L+R)6.3mm jack (+28dBu balanced / +22dBu unbalanced) Digital input/output USB type B connector Class compliant device Aux send, Effects send, Rec out unbalanced 6.3mm jack (+22dBu) Phones output +15dBu stereo 6.3mm jack
